Automatic Weighing Packaging Line
Products
Home Linear Weigher 2 Head Linear Weigher

Double Head 8.0L Linear Weigher

High qualilty linear weigher

Double Head 8.0L Linear Weigher

Applicable for weighing of different kinds of granular, powdered products such as sugar, rice, chicken essence, seeds, salt, powdered milk / coffee / seasoning, etc.

  • Order(MOQ):

    1
  • Payment:

    T/T
  • Product Origin:

    Hefei City, Anhui Province, China
  • Color:

    Silver
  • Shipping Port:

    Shanghai, Ningbo, Guangzhou
  • Lead Time:

    Ready In Stock

UUPAC Double Head 8.0L Linear Weigher



 2 Head Linear Weigher



|| Production Description

UUPAC Double head linear weigher  systems with vibrating channels, LW series, are the perfect solution to weight automatically all the products of medium granulometry (up to 1000 Gr.). The precision in the weighing is ensured by 2 independent roughing and finishing vibrating channels at various vibrations.

The hoppers, baskets and vibrating channels can be customized and in this way it is possible to dose all the range of products. LW machines can create up to 4 MIX of various products. The LW dosing systems have from 2 weighing heads and can be coupled with the automatic packaging machines when needed.





|| Features of UUPAC Linear Weigher

1. 7” color touch screen with multi-language operating system. Software can be upgraded through USB.

2. SUS304 / 316 body structure for option. IP65 dust and water proof design.

3. Restoration function of factory parameter. 99 product parameters can be preset to meet different parameter program requirements.

4. Amplitude can be automatically adjusted for easy operation.

5. Each hopper can function as one head weigher.

6. Able to weigh and package two different products.

7. Open-close mode of step motor drive to make the machine running faster and more stable.

8. Modular control system design for easy maintenance and cost-saving.



|| Machine Details

2 head linear weigher



|| Detailed Data

Model

TY-A-Mx2-80

Max. Weighing (one hopper)

1,000g

Accuracy

x (0.5)

Min. Scale Interval

0.1g

Max. Speed

10-30 WPM

Hopper Volume

8.0L

Control System

MCU

HMI

7” color touch screen

Power Supply

AC220V ±10% 50HZ/60HZ, 1KW

Packing Dimension

1,306(L)×1,000(W)×1,295(H)mm

Net Weight

150kg

Gross Weight

230kg
